ZV 040 K0 GEO (for CONTI POLYFLAT, for External Screw M16)
Wedge Socket
Specifications
Dimensions
Wedge Socket Description
ZV 040 K0 GEO (for CONTI POLYFLAT, for External Screw M16) are wedge sockets used for fastening CONTI POLYFLAT flat belts and CONTI POLYROPE elevator belts. They consist of a cast iron housing in which the flat belt is inserted and secured with a special wedge against loosening. Depending on the method of attachment, they can be fixed with a bolt or with a bolt and a spring.
Construction
- Socket housing
- Belt
- Wedge
- Eyebolt
- Nut
- Split pin
- Pin
- Washer
- Cable clamp
Typical Applications
Wedge sockets for CONTI POLYFLAT and CONTI POLYROPE belts are used in elevators and lifting systems. They are certified for use in passenger elevators according to the EN 81-20/50 Standard.
They are available in various widths according to the respective flat belt.
